KERA-BIBER PROFIL Saxony plain tile natural red

KERA-BIBER PROFIL Saxony plain tile 18x38x1.2, segmented cut

The plain tile with the profiled surface.

natural red
natural red

Technical data

Size (approx.)180 x 380 x 12 mm
Max. coverage width (approx.)180 mm
Covering length on av. approx.155 mm
Max. gauge (approx.)165 mm
Min. gauge (approx.)145 mm
Average tile requirement (approx.)36 pcs/m²
Weight per m² (approx.)73.8 kg/m²
Weight per pallet (approx.)985 kg
Unit weight (approx.)2 kg/Stück
Pcs per pallet480 Unit
Pcs per mini-pack8 piece

Area of use

VALID FOR GERMANY
Roof pitch DUO extra (Germany)≥ 22 °
Roof pitch QUATTRO longlife extra (Germany)≥ 10 °
Roof pitch TRIO extra (Germany)≥ 18 °
VALID FOR AUSTRIA
Roof pitch DUO extra (Austria)≥ 25 °
Roof pitch QUATTRO longlife extra (Austria)≥ 25 °

Technical informations

  • Current national rules and standards apply to the execution of roofing work. These vary from country to country (e.g. ZVDH Rules, Austrian Standards) and must be taken into consideration during execution. As manufacturer's information, CREATON-specific information about the execution of the sub-roof is also applicable and is complementary to these. You can find them in our Roof Planner or at www.creaton.de / www.creaton.at.
  • The technical drawing shown is merely an example.
  • According to the Central Association of the German Roofing Trade (ZVDH) rules for verge tiles, the distance between the inner edge of the verge lug and the outer edge of the gable wall or cladding must be at least 1 cm.
  • Batten spacing / tile gauge is dependent on the roofing type and roof pitch.
